SQUAD
SQUAD is a recessed downlight fixture. The main structure is constructed from aluminum alloy with a sandblasted finish. The wick is of high quality, ensuring durability and energy efficiency. Its design is simple, featuring an effective heat dissipation system, and it is easy to install. This fixture is suitable for lighting designs in upscale modern residences and commercial environments. The light produced is aesthetically pleasing, uniform, and subtle, free from glare or flicker.
Description
Housing: Main aluminum alloy, sandblasting process
Available: White, Black, Black & White
Reflector: PS Reflector
Voltage: AC 220 – 240
120lm/W
Anti – glare, Flicker free
Reflector: Aluminum Reflector
Voltage: AC220~240 V
Tridonic driver flink free, CREE led chip
Working Temperature: -20°C ~ 55°C
| Model # | Power | LUMEN | Dimensions mm |
|---|---|---|---|
| VL20207S | 7W | 840 | A65 X B65 X C52 |
| VL20212S | 12W | 1440 | A85 X B85 X C62 |
| VL20218S | 18W | 2160 | A105 X B105 X C77 |
| VL20207S2 | 2X7W | 1680 | A125 X B65 X C52 |
| VL20212S2 | 2X12W | 2880 | A167 X B85 X C62 |
| VL20218S2 | 2X18W | 4320 | A210 X B105 X C77 |
