ARROW
ARROW is Aluminum profiles or channels are constructed from durable anodized or powder-coated aluminum and are specifically designed to safeguard LED strips while producing a softer lighting effect. These aluminum profiles or channels serve as excellent housing and effective heat sinks for flexible LED strips. They are suitable for a variety of ceiling applications, including hotels, supermarkets, offices, exhibitions, workstations, and any other visible installations where the lighting strips are exposed.
Description
Housing: Die cast Aluminum
Diffuser: Tempered Glass Diffuser
Color Available: ALL COLOR as request (powder coated)
Lifespan: >50,000 Hours
Reflector: Aluminum
Voltage: AC220~240V
Working Temperature: -10C° ~ 55C°
CREE LED chips
Dreiver : Tridonic
| Model # | Power | LUMEN | Dimensions mm |
|---|---|---|---|
| VLPL3036 | 36W | 4320 | A1204 x B56 x C75 |
| VLPL3042 | 42W | 5040 | A1504 x B56 x C75 |
| VLPL3050 | 50W | 6000 | A1204 x B56 x C75 |
| VLPL3060 | 60W | 7200 | A1504 x B56 x C75 |
